Model
RG-EG2100-P v2
Hardware Specification
CPU
Multi-core MIPS
Fixed Ports
8 1000BASE-T ports (7x POE/POE+)
WAN Ports
Upto 2
Flash
4GB EMMC
Hard Disk
N/A
Memory
512M
Performance & Feature
Performance
1000Mbps (1518 bytes)
450Mbps (512bytes)
70Mbps (64 bytes)
Concurrent Session
100,000
Recommended Concurrent User
300
Portal Authentication Capacity
100 (Max Concurrent Users)
Portal Authentication Type
Username/Password Auth (Local, Windows-based AD/LDAP Integration)
One-click Authentication;
Guest Voucher (Ruijie Cloud required);
Seamless Authentication (Portal)
Support
App Caching
Cache Capacity
750MB
Cache Resources
Android APK files (non-https server required)
Network Protocol
Support TCP/IP protocols, including IP, ICMP, TCP, UDP, etc.
Support multiple routing protocols, including static routing, RIP (V1 / V2) and OSPF
Support DHCP Relay and DHCP Server
Support PPPoE Client
Support NAT and multiple NAT ALG including FTP, H.323, DNS, etc.
Support ARP, trusted ARP, proxy ARP, etc.
Support Ping and Traceroute fault detection
Application Visibility
Support self-developed 43 types of applications / more than 120 application features, customizable protocol identification:
P2P: BitTorrent, eMule, Thunder, EDONKEY, FlashGet & etc.
Multimedia: YouTube, Facebook Video, WebEx Conference & etc.
Social Media: Facebook, Twitter, LinkedIn, Pinterest & etc.
VOIP/Chat: Skype, Viber, Google Hangout, Jabber, Facebook Messenger & etc.
Instant Messaging/Email: Gmail, MSN, QQ, YAHOO & etc.
Software Update: Window, McAfee, Kaspersky, ESET & etc.
Cloud-based File Collaboration: GoogleDrive, Dropbox, OneDrive, iCloud & etc.
Enterprise Application：HTTP, FTP, SMTP, POP3, IMAP, Telnet, LOTUS-NOTES, SQL Server, Oracle, Mysql, HTTPS & etc.
URL Filtering
Support custom URLs Support remote HTTP automatic URL library upgrade Local log storage (NAT log, traffic log, URL log, etc.) Support storage on external log server
WAN Load Balancing
Support (upto 2 WAN Port)
IPsec VPN Tunnel
16
Network Security
Anti-ARP Spoofing Defense against malicious attacks from internal and external networks Support secure address binding Block WAN Ping Prevent Port Scan Attack Prevent Fragmentation Attack Prevent ICMP Flood Attack Prevent Teardrop Attack Prevent Ping of Death Attack Prevent Land Attack Prevent Smurf / Fraggle attack Prevent SYN Flood Attack
Ruijie Cloud Integration Feature
Support device health monitoring status
Support centralized configuration change management & backup
Support Top 10 Application/User traffic visualization
Support device firmware management
Support event-based alarm notification
Other Features
Integrate with AAA software to support multiple authentication modes
Service and Support
Support push advertising page
Support multi-link load balancing
Support remote HTTP online upgrade for signature library, software version, etc.
Lifetime Free signature library upgrade
Rack Height
1U
Weight
2KG
Power Supply
100-240V~,50-60Hz,3A
PoE Budget
135W
Power Consumption
<150W
Dimensions (W x D x H) (mm)
200×200x43.6
Operating Temperature
0°C to 45°C
Operating Humidity
10% to 90%RH
